Home / Products / HXZ The Powerful Two-platen Injection Molding Machine / HXZ2400: two plate injection molding machinery series
HXZ2400: two plate injection molding machinery series
HXZ The Powerful Two-platen Injection Molding Machine

HXZ2400: two plate injection molding machinery series

The 2400T two-platen machine is equipped with a mold positioning device that can be regarded as a paragon of precision. The precision ball screw adopted therein, with its ultra - high manufacturing accuracy and stable transmission performance, can accurately control the error of mold installation and positioning within a very small range. Paired with a high-resolution encoder, it is like equipping the equipment with a pair of "clairvoyant eyes", which can monitor the position status of the mold in real-time and accurately, ensuring the accuracy of mold installation and positioning. At the same time, the advanced injection control system adopts closed-loop control technology to construct a precise feedback adjustment network. It continuously monitors key parameters such as injection volume, injection speed, holding pressure, and time in real-time.

E-mail: haixiong@highsun-machinery.com
Contact Us
  • HXZ2400: two plate injection molding machinery series
PREV：HXZ2800: two plate injection molding machinery series
NEXT：HXZ2100： two plate injection molding machinery series

  • MODEL: HXZ2400

    TECHNICAL PARAMETER TABLE

    A

    B

    C

    INJECTION UNIT

    SCREW DIAMETER

    mm

    165

    175

    185

    SCREW L/D RATIO

    L/D

    22

    21

    20

    INJECTION CAPACITY IN THEORY

    cm³

    20099

    22609

    25267

    INJECTION WEIGHT(PS)

    g

    18290

    20574

    22993

    INJECTION PRESSURE

    MPa

    160

    142

    127

    INJECTION RATE

    g/s

    1521

    1711

    1918

    PLASTICIZING CAPACITY

    g/s

    115

    135

    170

    SCREW SPEED

    rpm

    66

    CLAMPING UNIT

    CLAMPING FORCE

    KN

    24000

    MOVING MOULD-PLATE STROKE

    mm

    3300/2200

    MAX. MOULD HEIGHT

    mm

    1900

    MIN. MOULD HEIGHT

    mm

    800

    MAX DAYLIGHT OPENING

    mm

    4100

    SPACE BWTWEEN TIE-BARS (W*H)

    mm

    1920*1720

    HYDRAULIC EJECTOR FORCE

    KN

    520

    HYDRAULIC EJECTOR STROKE

    mm

    520

    EJECTOR NUMBER

    n

    25

    OTHERS

    PUMP PRESSURE

    MPa

    25

    MOTOR POWER

    KW

    40+40+47+47

    HEATING CAPACITY

    KW

    214.15

    MACHINE DIMENSION (L*W*H)

    m

    14.5*5.1*4.8

    OIL TANK CAPACITY

    L

    2200
